1170W 48V (6x Bifacial 195W) Complete MPPT Off Grid Solar Kit

Product image 1
1 / 10
+5

1170W 48V (6x Bifacial 195W) Complete MPPT Off Grid Solar Kit

Package Includes
6x Bifacial 195W Mono Solar Panel
1x 3000W 48V All-in-one Inverter
1x 5M 12AWG Extension Cable with MC4
2x 5M 12AWG MC4-MC4 Extension Cable
6x Z Mounting Bracket
Battery Bank Options-

5.12kWh Lithium Battery Bank (optional)
with
1x 48V 100Ah  LiFePO4 Lithium Battery

Bifacial 195W Monocrystalline Solar Panel

Rated Power: 195W Solar Cell: Monocrystalline
Maximum/Peak Voltage(Vmp): 19.8V Open Circuit Voltage(Voc): 23.7V
Short circuit current: 10.5A Maximum current: 9.85A
Output Tolerance: ±3% Temperate coefficient of Isc: (010+/-0.01)%/℃
Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ Temperature range: -40℃~ +85℃
Frame: Aluminum alloy frame Weight: 20.48 lbs(9.29 kg)
Size: 52.6x26.38x1.38in (1335*670*35mm)

All-in-one Inverter(3000W 48V Inverter+60A controller)

Models: ECO3000W(SR) AC Rated input voltage: 220/230Vac
AC Frequency: 50Hz/ 60Hz (Auto detection) AC Overload/short circuit protection: 10ms (typical)
AC Maximum Efficiency: Available AC Maximum bypass overload current: 30A
Output voltage waveform: Pure sine wave Rated output power (W): 3300w
Rated output voltage (Vac): 230Vac Output voltage error: ±5%
Output frequency range (Hz): 50Hz ± 0.3Hz / 60Hz ± 0.3Hz Efficiency: >92%
Size (L*W*D): 378mm*280mm*103mm Weight (kg): 6.2

48v 100Ah LiFePO4 Lithium Battery

Battery Capacity: 100Ah Battery Power: 5120Wh
Rated Voltage: 51.2V Voltage Range: 40~58V
Maximum Charge/ Discharge Current: 100A Charge Temperature Range: 0-55℃
Disharge Temperature Range:﹣20-55℃ Maximum Charge Voltage: 58.4V
Screw size: M8 Battery Size: 22.55*17.13*5.63inch
Battery Weight: 99 lbs Each battery comes with a pair of battery parallel cables
Certification Test:IEC62619

16.4 feet 12AWG Cables

Cable Type: Connecting Solar Panels to Charge Controller Rating Voltage: 600/1000V
Length: 5 meters(16 ft) Conductor: Tinned copper wire
AWG: 11 Normal Cross Sectional Area of the Conductor (mm2): 4
Waterproof: IP 65 Protection Temperature: -40°F to +185°F
Connector: MC4 Weight: 0.742KG

Z Mounting Brackets

6 pieces of Z shape solar panel brackets 12 pieces of stainless steel nuts and cap bolts

Package Includes
6x Bifacial 195W Mono Solar Panel
1x 3000W 48V All-in-one Inverter
1x 5M 12AWG Extension Cable with MC4
2x 5M 12AWG MC4-MC4 Extension Cable
6x Z Mounting Bracket
Battery Bank Options-

5.12kWh Lithium Battery Bank (optional)
with
1x 48V 100Ah  LiFePO4 Lithium Battery

Bifacial 195W Monocrystalline Solar Panel

Rated Power: 195W Solar Cell: Monocrystalline
Maximum/Peak Voltage(Vmp): 19.8V Open Circuit Voltage(Voc): 23.7V
Short circuit current: 10.5A Maximum current: 9.85A
Output Tolerance: ±3% Temperate coefficient of Isc: (010+/-0.01)%/℃
Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ Temperature range: -40℃~ +85℃
Frame: Aluminum alloy frame Weight: 20.48 lbs(9.29 kg)
Size: 52.6x26.38x1.38in (1335*670*35mm)

All-in-one Inverter(3000W 48V Inverter+60A controller)

Models: ECO3000W(SR) AC Rated input voltage: 220/230Vac
AC Frequency: 50Hz/ 60Hz (Auto detection) AC Overload/short circuit protection: 10ms (typical)
AC Maximum Efficiency: Available AC Maximum bypass overload current: 30A
Output voltage waveform: Pure sine wave Rated output power (W): 3300w
Rated output voltage (Vac): 230Vac Output voltage error: ±5%
Output frequency range (Hz): 50Hz ± 0.3Hz / 60Hz ± 0.3Hz Efficiency: >92%
Size (L*W*D): 378mm*280mm*103mm Weight (kg): 6.2

48v 100Ah LiFePO4 Lithium Battery

Battery Capacity: 100Ah Battery Power: 5120Wh
Rated Voltage: 51.2V Voltage Range: 40~58V
Maximum Charge/ Discharge Current: 100A Charge Temperature Range: 0-55℃
Disharge Temperature Range:﹣20-55℃ Maximum Charge Voltage: 58.4V
Screw size: M8 Battery Size: 22.55*17.13*5.63inch
Battery Weight: 99 lbs Each battery comes with a pair of battery parallel cables
Certification Test:IEC62619

16.4 feet 12AWG Cables

Cable Type: Connecting Solar Panels to Charge Controller Rating Voltage: 600/1000V
Length: 5 meters(16 ft) Conductor: Tinned copper wire
AWG: 11 Normal Cross Sectional Area of the Conductor (mm2): 4
Waterproof: IP 65 Protection Temperature: -40°F to +185°F
Connector: MC4 Weight: 0.742KG

Z Mounting Brackets

6 pieces of Z shape solar panel brackets 12 pieces of stainless steel nuts and cap bolts
$893.05

Original: $2,551.57

-65%
1170W 48V (6x Bifacial 195W) Complete MPPT Off Grid Solar Kit

$2,551.57

$893.05

Description

Package Includes
6x Bifacial 195W Mono Solar Panel
1x 3000W 48V All-in-one Inverter
1x 5M 12AWG Extension Cable with MC4
2x 5M 12AWG MC4-MC4 Extension Cable
6x Z Mounting Bracket
Battery Bank Options-

5.12kWh Lithium Battery Bank (optional)
with
1x 48V 100Ah  LiFePO4 Lithium Battery

Bifacial 195W Monocrystalline Solar Panel

Rated Power: 195W Solar Cell: Monocrystalline
Maximum/Peak Voltage(Vmp): 19.8V Open Circuit Voltage(Voc): 23.7V
Short circuit current: 10.5A Maximum current: 9.85A
Output Tolerance: ±3% Temperate coefficient of Isc: (010+/-0.01)%/℃
Temperate coefficient of Voc: -(0.38+/-0.01)%/℃ Temperature range: -40℃~ +85℃
Frame: Aluminum alloy frame Weight: 20.48 lbs(9.29 kg)
Size: 52.6x26.38x1.38in (1335*670*35mm)

All-in-one Inverter(3000W 48V Inverter+60A controller)

Models: ECO3000W(SR) AC Rated input voltage: 220/230Vac
AC Frequency: 50Hz/ 60Hz (Auto detection) AC Overload/short circuit protection: 10ms (typical)
AC Maximum Efficiency: Available AC Maximum bypass overload current: 30A
Output voltage waveform: Pure sine wave Rated output power (W): 3300w
Rated output voltage (Vac): 230Vac Output voltage error: ±5%
Output frequency range (Hz): 50Hz ± 0.3Hz / 60Hz ± 0.3Hz Efficiency: >92%
Size (L*W*D): 378mm*280mm*103mm Weight (kg): 6.2

48v 100Ah LiFePO4 Lithium Battery

Battery Capacity: 100Ah Battery Power: 5120Wh
Rated Voltage: 51.2V Voltage Range: 40~58V
Maximum Charge/ Discharge Current: 100A Charge Temperature Range: 0-55℃
Disharge Temperature Range:﹣20-55℃ Maximum Charge Voltage: 58.4V
Screw size: M8 Battery Size: 22.55*17.13*5.63inch
Battery Weight: 99 lbs Each battery comes with a pair of battery parallel cables
Certification Test:IEC62619

16.4 feet 12AWG Cables

Cable Type: Connecting Solar Panels to Charge Controller Rating Voltage: 600/1000V
Length: 5 meters(16 ft) Conductor: Tinned copper wire
AWG: 11 Normal Cross Sectional Area of the Conductor (mm2): 4
Waterproof: IP 65 Protection Temperature: -40°F to +185°F
Connector: MC4 Weight: 0.742KG

Z Mounting Brackets

6 pieces of Z shape solar panel brackets 12 pieces of stainless steel nuts and cap bolts
